DynaLoc™ Type 2 Indoor Magazine

Call for Price

U.S. Chemical Storage engineers durable Type 2 indoor magazine storage for storing high explosives (up to 50 lbs.) inside your facility. The portable steel construction-lined hardwood storage magazines keeps your explosive components or ammunition secure and safe.

Description

Manufacturer: U.S Chemical Storage

U.S. Chemical Storage engineers durable Type 2 indoor magazine storage for storing high explosives (up to 50 lbs.) inside your facility. The portable steel construction-lined hardwood storage magazines keeps your explosive components or ammunition secure and safe.

Type 2 Indoor Magazine Storage Building Features & Benefits

  • Bullet-resistant
  • Theft-resistant
  • 12-gauge steel construction lined with ¾-inch or ½-inch of hardwood
  • Front-open and top-open styles available
  • Secure double locking door system with ¼-inch steel hood features hinges and hasps welded to door – cannot be removed when the door is closed and locked
  • Interior and exterior surfaces protected with high-performance 2-part epoxy primer and polyurethane topcoat for resistance to chemicals, exterior abrasion, corrosion and UV
  • Durable 4-inch casters allow mobility (on some models)
  • Seven standard models

Explosive Storage Magazine Compliance

All magazines meet and exceed:

  • ATF 27 CFR, Part 555.208
  • DoD 5100

Common Applications

  • Military/law enforcement explosive and ammunition storage
  • Municipal explosive and ammunition storage
  • Contractor explosive and ammunition storage

Downloadable Information

Mag Storage Design Sheet

DynaLoc General Sell Sheet v2-200305 WEB

Type 2 Indoor Storage Magazine Sizes

Type 2 Indoor Storage Magazine

Dimensions Exterior: 36 x 24 x 36 in (LxWxH)
Dimensions Interior: 34.8 x 22.8 x 34.8 in
Approximate Weight: 340 lbs.

Type 2 Indoor Storage Magazine

Dimensions Exterior: 48 x 24 x 48 in (LxWxH)
Dimensions Interior: 46.8 x 22.8 x 46.8 in
Approximate Weight: 489 lbs.

Type 2 Indoor Storage Magazine

Dimensions Exterior: 60 x 28 x 72 in (LxWxH)
Dimensions Interior: 58.8 x 26.8 x 70.8 in
Approximate Weight: 806 lbs.

Type 2 Indoor Detonator Box or “Cap Box”

Dimensions Exterior: 18 x 18 x 18 in (LxWxH)
Dimensions Interior: 16.8 x 16.8 x 16.8 in
Approximate Weight: 114.65 lbs.

Type 2 Indoor Detonator Box or “Cap Box”

Dimensions Exterior: 24 x 24 x 24 in (LxWxH)
Dimensions Interior: 22.8 x 22.8 x 22.8 in
Approximate Weight: 173 lbs.

Type 2 Indoor Detonator Box or “Cap Box”

Dimensions Exterior: 30 x 24 x 18 in (LxWxH)
Dimensions Interior: 28.8 x 22.8 x 16.8 in
Approximate Weight: 169.85 lbs.

Type 2 Indoor Detonator Box or “Cap Box”

Dimensions Exterior: 30 x 24 x 30 in (LxWxH)
Dimensions Interior: 28.8 x 22.8 x 28.8 in
Approximate Weight: 225 lbs.
